HSIL Nephrocure SWS 5000 CRRT Machine

The SWS-5000 CRRT System is a fully integrated blood purification platform designed for intensive care units, nephrology departments, and critical care applications. Developed by SWS Medical, it supports up to 14 advanced blood purification therapies, including CVVH, CVVHD, CVVHDF, SCUF, Hemoperfusion (HP), Plasma Exchange (PE), Plasma Adsorption (PA), CPFA, DFPP, MARS, FPSA, SPAD, RAD, and PDF, enabling clinicians to address a wide range of renal, hepatic, septic, and critical care conditions.

Send Enquiry

Product Category: Dialysis Machines

Features Why Choose This Detailed Specifications

Supports up to 14 blood purification treatment modes, including CVVH, CVVHD, CVVHDF, SCUF, HP, PE, PA, CPFA, DFPP, MARS, FPSA, SPAD, RAD, and PDF.
Designed for Continuous Renal Replacement Therapy (CRRT) and advanced blood purification procedures.
Integrated citrate anticoagulation system with dedicated infusion pump and weighing scale.
Dual-channel substitution fluid input for accurate replacement fluid management.
Five high-precision peristaltic pumps with flow rates up to 600 mL/min.
Advanced 4-scale fluid balance system for precise ultrafiltration and fluid control.
Fluid balance accuracy up to ±5 g with cumulative balance error ≤ 100 mL.
Real-time monitoring of venous pressure, arterial pressure, transmembrane pressure, and membrane pressures.
Temperature-controlled replacement fluid delivery with a control range of 33°C to 40°C.
Blood leakage detection and air bubble monitoring for enhanced patient safety.
Large rotatable touchscreen interface for convenient operation.
One-button priming and treatment mode switching for faster setup.
Guided tubing installation with visual instructions.
Supports pre-dilution, post-dilution, and mixed dilution therapy modes.
Automatic recognition of 10 mL, 20 mL, 30 mL, and 50 mL syringes.
Backup battery support for uninterrupted monitoring during power interruptions.
Suitable for ICU, nephrology, critical care, liver support, sepsis management, poisoning treatment, and advanced blood purification applications.
Compact and ergonomic design for easy movement within clinical environments.
Reliable components, including high-quality motors, sensors, and pumps for long-term performance.
Compatible with a wide range of blood purification consumables and treatment protocols.

The SWS-5000 combines multi-therapy flexibility, precise fluid balance control, intelligent monitoring systems, and user-friendly operation in a single platform. Its comprehensive treatment capabilities make it an ideal solution for hospitals, dialysis centers, and critical care units seeking reliable and advanced blood purification technology.

1. Basic Information

Parameter	Specification
Height	1720 mm
Width	635 mm
Thickness	578 mm
Weight	About 75 Kg

Electrical Parameters

Parameter	Specification
Voltage	~110/220V
Frequency	50/60 Hz
Power	500 VA
Backup Battery Capacity	2 × 12V / 4Ah

2. Flow Monitoring

Parameter	Range	Accuracy
Blood Pump Flow (BP)	30 mL/min ~ 600 mL/min	Set Value ±10%
LP1	1 mL/min ~ 250 mL/min	±0.1 mL/min or ±5% of Set Value
Waste Liquid Pump Flow (UFP)	1 mL/min ~ 250 mL/min	±0.1 mL/min or ±5% of Set Value
LP2	1 mL/min ~ 250 mL/min	±0.1 mL/min or ±5% of Set Value
Function Pump Flow (FP)	1 mL/min ~ 250 mL/min	±0.1 mL/min or ±5% of Set Value

Infusion Pump Flow

Parameter	Specification
Flow Adjustable Range	0 mL/h ~ 10 mL/h
Error Range	±0.2 mL/h or Reading ±5%
Rapid Injection Flow	10 mL/h ~ 2000 mL/h
Syringe Specification	10 mL / 20 mL / 30 mL / 50 mL

Additional Parameters

Parameter	Specification
Dehydration Error	≤ ±20 mL/h
Liquid Balance Control	≤ 100 mL

3. Pressure Monitoring

Monitoring Type	Range	Accuracy
Venous Pressure Monitoring (VP)	-500 mmHg ~ +700 mmHg	±5 mmHg
Arterial Pressure Monitoring (AP)	-500 mmHg ~ +700 mmHg	±5 mmHg
Transmembrane Pressure Monitoring (TMP)	-500 mmHg ~ +700 mmHg	±5 mmHg
Primary Membrane External Pressure Monitoring (PM1)	-500 mmHg ~ +700 mmHg	±5 mmHg
Secondary Membrane Pressure Monitoring (PM2)	-500 mmHg ~ +700 mmHg	±5 mmHg

4. Liquid Balance Control

Scale Type	Range	Accuracy
Rehydration Scale	0 Kg ~ 30 Kg	±5 g or ±0.1%
Waste Liquid Scale	0 Kg ~ 30 Kg	±5 g or ±0.1%
Auxiliary Rehydration Scale I	0 Kg ~ 12 Kg	±5 g or ±0.1%
Auxiliary Rehydration Scale II	0 Kg ~ 12 Kg	±5 g or ±0.1%

Total Scale Number: 4

5. Substitution Fluid Flow Temperature Control

Parameter	Specification
Control Range	33°C ~ 40°C
Accuracy	Control Error ±1°C

6. Safety Monitoring

Monitoring Type	Specification
Blood Leakage Monitoring	≤ 0.35 mL/min (HCT 32%)
Air Monitoring	> 0.02 mL Bubbles

7. Each Model Treatment Mode Contrast

Treatment Mode	SWS-5000 (Full Function)	SWS-5000 (Professional)	SWS-5000A	SWS-5000B
Citrate Anticoagulation	✓	✓	✓	✗
Substitution Double Channel Input	✓	✓	✓	✗
CVVH – Continuous Veno-Venous Hemofiltration	✓	✓	✓	✓
CVVHD – Continuous Veno-Venous Hemodialysis	✓	✓	✓	✓
CVVHDF – Continuous Veno-Venous Hemodiafiltration	✓	✓	✓	✗
SCUF – Slow Continuous Ultrafiltration	✓	✓	✓	✓
HP – Hemoperfusion	✓	✓	✓	✓
PE – Plasma Exchange	✓	✓	✓	✓
PA – Plasma Adsorption	✓	✓	✓	✓
CPFA – Continuous Plasma Filtration and Adsorption	✓	✓	Optional	✗
FPSA – Fractional Plasma Separation and Adsorption	✓	Optional	Optional	✗
MARS – Molecular Adsorbent Recycling System	✓	Optional	Optional	✗
SPAD – Single Pass Albumin Dialysis	✓	Optional	Optional	✗
DFPP – Double Filtration Plasmapheresis	✓	Optional	Optional	✗
RAD – Repeated Pass Albumin Dialysis	✓	Optional	Optional	✗
PDF – Plasmadiafiltration	✓	Optional	Optional	✗

Legend

✓ = Available
○ = Optional
✗ = Not Available
